BONOVO customizable S SERIES excavator bucket for excavation project

Home> Products > Excavator Attachments

All types of Bonovo buckets available.
Bonovo keep a full range buckets and attachments with “S” type brackets in stock now .

GET IN TOUCH

Commonly used tonnage parameters:

Type	Tonnes	Capacity	Weight
Digging bucket S40	4-5T	250lt	186
Digging bucket S50	6-8T	400lt	296
Digging bucket S60	10-14T	750lt	672
Digging bucket S70	17-22T	1150lt	990

Raw materials: Many types of steel plates are available :Q345,NM400,HARDOX,etc The material will be quality-inspected when they are delivered to the workshop.

Machining Area:

--Drilling & Boring

-Mainly drill the holes in bushing and side cutting edge.

-Accurate inner diameter of bushing to make sure the pins match the bushing perfectly.

--Milling

-Processing flange plate (CAT and Komatsu excavator over 20 ton bucket will use flange plate).

--Beveling

-Make groove at steel plate to increase the welding area and make sure more solid welding.

Welding advantages:

Welding Area-The most remarkable of our advantage

-Bonovo uses carbon dioxide gas shielded welding machine and flux-cored wire ,which is adapted to any position in space . Multi-pass welding and multi-layer welding are all our feature.

-Adapter and blade edge are both through preheated before welding. The temperature is controlled reasonably between 120-150℃

-The welding voltage is maintained at 270-290 volts , and the current is maintained at 28-30 amps to ensure the stability of welding process

-Experienced welders are technically skilled with double hands , which makes the weld seam achieve graceful fish-scale shape

Shot blasting advantages:

1.Remove the surface oxide layer of the product

2.Releasing the welding hard force generated during welding

3.Increase the paint's adhesion and make the paint more firmly absorbed on the steel plate.

Inspection

From raw materials to finished products, the whole process is under strict quality inspection included flaw detection，weld inspection,structure size inspection,surface inspection,painting inspection,assembly inspection,package inspection etc.to keep our quality standard，
