DIG-DOG Excavator Sales | DG10 Mini Excavator with multiple attachments

Tonnage: 1.0 tons
Engine: KOOP/Kubota
Additional features: boom side swing, Retractable undercarriage, 4 Pillar FOPS Canopy.
Walking Motor Brand: Eaton Motor

GET IN TOUCH

DG10 mini Excavator with Tailless small wing structure and boom-side-shift option, which can be used for narrow-space operation tailless rotation, retractable chassis,deflective boom, first-class configuration, load sensitive system, changeable rubber track, environmental protection standard

This product with beautiful appearance, high configuration,superior perfomance,low fuel consumption,wide operating range. It is suitable for loosing soil of vegetable greenhouse,campus greening of municipal departments. digging the hole for tree planting of Fuit-land Nurseries. concrete pavement crushing,sand-gravel material mixing, construction work in the narrow place and so on. Use the quick hitch can add the attachment tools like auger,hydraulic hammer,ditching bucket,gripple,thumb,tilt bucket,ripper,rake and so on. It can reduce maintenance and operating costs, iberate the workforce improve the mechanization, low investment, high return. Bonovo is willing to provide you with construction plans and procurement plans.

Specifications of DG10

About Weight

How will you transport your excavator? Make sure it isn’t too heavy for the setup you plan to use. Otherwise, you’ll cause too much strain to your hauling vehicle, or you won’t be able to move the excavator at all.

Machine model No.	DG10
Type of tracks	Rubber track
Machine weight	1940lbs/880kg
Bucket Capacity	0.02m³
System Pressure	16Mpa
Max. grade ability	30⁰
Max.Bucket Digging Force	14KN
Operation type	Mechanical lever

Overall Parameters of DG10

About Sizes:

All mini excavators are smaller than full-sized ones, but there are different sizes within the mini category. Some may still be too large for your job, while others may be too small.

To determine what size of excavator you need, you’ll have to evaluate your worksite. The excavator must be able to fit into the area that needs to be worked. This means it must be able to maneuver correctly, not just fit.

When looking at size, consider height, width, and length. Otherwise, you may end up with a dimension that doesn’t work.

Engine	Model	CHANGCHAI/KOOP
	Displacement	0.499L
	Type	single-cylinder diesel
	Max. Power	7kW/1800r/min
	Max. Torque	26.8N.m
Overall Dimensions	Overall Length	2120mm
	Overall Width	930mm
	Overall height	2210mm
	Chassis width	930mm
	Upper chassis ground clearance	410mm
	Cabin height	2210mm

Blade	Width	930mm
	Height	235mm
	Max.lift of dozer blade	325mm
	Max.depth of dozer blade	175mm
Hydraulic system	Pump type	Gear pump
	Pump capacity	22L/Min
Motor	Traveling motor	Eaton 310
	Swing motor	KERSEN

About Arm Length

Different excavators come with different arms. Since the arm is one of the most important parts of the excavator, make sure it will work for what you need it to do.

Consider your project and workspace. Will a standard arm do the trick? If not, find a size that works for you.

Excavator arms are available in long and extendable sizes. These allow for longer reach and higher dump height.

It won’t do you much good if your excavator can’t reach the container it’s supposed to dump stuff in, so make sure it’s the right size.

Working range	Max.Digging Height	2490mm
	Max.Dumping Height	1750mm
	Max.Digging Depth	1400mm
	Max.Vertical Digging Depth	1320mm
	Max.Digging Radius	2400mm
	Min.Swing Radius	1190mm
	Tail Swing Radius	795mm
